Specification
Input Section
1/4" jack
1 MOhm / 100 pF
-96 to 32 dB
Default Freq: 200 Hz (range: 71-1120 Hz, Gain: +15/-24 dB) - Shelving type.
Default Freq: 400 Hz (range: 100-1600 Hz, Gain: +15/-24 dB)
Default Freq: 800 Hz (range: 200-3150 Hz, Gain: +15/-24 dB)
Default Freq: 4000 Hz (range: 400-6300 Hz, Gain: +15/-24 dB) - Shelving type.
-12 to 12, L-PAD Cabinet Recreation
0 to 12, Tube amp Recreation
3 band Spectral Compression
-12 dB to 0 gain attenuation
3 memory locations storing all front panel controls except Mute & Master Level
Chromatic, constant on A0 (27.50 Hz) to E5 (659.26 Hz)
100-120V~ or 220-240V~ 50/60 Hz (200 W @ 1/8 Power)
2x Speakon™
1600W (3000W inst. Peak @ min. Load) TCE Power rating and Active Power Management
Recessed Toggle Switch
+0 dBu
600 Ohm
1/4" Jack, Balanced Output, Max Output Level = +8 dBu
1/4" Jack, balanced input, impedance = 10 kOhm, Max Input Level = +8 dBu
Balanced XLR, AES/EBU, (24 Bit)
5 pin DIN, Cable with shield
0° C to 50° C / -30° C to 70° C
Max. 90 % non-condensing
483 x 412 x 178 mm / 19" x 16.2" x 7"
12 kg / 26.5 pounds
Anodized aluminum front plated and painted steel chassis
